NQ Ally Works Ute Trays – style, quality and functionality

Are buying a new 4wd or wanting to upgrade your existing setup? Well…you have come to the right place!

We have lots of standard options and can tailor a package to suit your needs. We can put together the most basic package to get you on the road, trade packages to keep you productive on the job, or touring packages because we all need a little down time for travelling the big lap down under.

Our complete range of Australian made heavy duty aluminium ute trays have been designed using the latest in 3D design and manufacturing technologies to ensure seamless style, functionality, fit and finish to integrate onto your vehicle. Boasting a strong, robust design and weighing only a fraction of a comparative steel constructed tray, you’d be mad not to. Our packages incorporate bolting track extrusions exclusively designed and used by us to allow fitment of optional accessories giving you the build flexibility to go all out right away or add extras at a later date. With functionality a key design consideration we have jam packaged features into our standard designs and styles that most other manufacturers will only class or offer as optional extras, or simply won’t offer at all.

Our standard tray sizes suit most makes, models and cab styles:

  • Dual Cab: 1850W x 1800L x 880H
  • Dual Cab Triton 1850W x 1600L x 880H
  • Dual Cab Landcruiser: 1850W x 1800L x 1015H
  • Extra Cab 1850W x 2100L x 880H,
  • Single Cab 1850W x 2400L x 880H
  • Single Cab Landcruiser 1850W x 2400L x 1015H

Should you want to have your 200 series Landcruiser wagon converted to a ute and maybe even throw in a chassis extension, we have you covered with options to suit most standard conversions available. Our standard 200 series tray sizes includes:

  • Converted 200 Series Landcruiser With Nil Chassis Extension 2000W x 1600L x 880H
  • Converted 200 Series Landcruiser With 650mm/700mm Chassis Extension 2000W x 2000L x 880H

Can’t decide which you need more, a full time tray or a full time canopy. Well why not have both? With our full time half tray/half canopy packages you get the best of both worlds. With clean, dust and water free storage up front and functional, dirty load carrying capability at the rear – WIN WIN!!

*All full time half tray half canopy packages are 70mm shorter than the standard tray lengths listed above.

Our jack off style canopy is also worth checking out to run on the back of your new heavy duty aluminium tray. Giving you the flexibility to remove it when not needed, or leave setup at base camp when enjoying those weekends away with the family. We have various standard jack off canopy options available to select from, so head on over to the NQ Ally Works Canopies page and take a look!

Package Types

Here at NQ Ally Works we understand that not everyone’s needs are the same and deciding what package type you want, need or simply even knowing what types are available can be daunting and confusing. To help you on this exciting journey below we have featured some of our most popular package types to help you get the ball rolling.



 Ute Tray Package

If you are tired of that dis-functional style-side tub, or simply need a stylish yet robust heavy duty aluminium ute tray to compliment your vehicle, an NQ Ally Works tray package is perfect for you. Designed with functionality, strength and style in mind these tray packages will be the centre piece of your 4×4. With loads of standard inclusions and numerous optional add-ons to suit your needs, it’s hard to go past an NQ Ally Works ute tray package.







Ute Tray & Jack Off Canopy Packages

With an NQ Ally Works tray and jack off canopy package, you have the flexibility to maintain perfect symmetry with a work/play balance. An NQ Ally Work tray and jack off (removable) canopy will allow you to accessorize one of our canopies with various module options. Allowing you to piece together your perfect remote work station setup, or a perfect get-away setup for your family to enjoy those weekends away. Come the working week the jack off canopy can either be re-mounted or removed depending on your work and play setup preference. Allowing you interchangeability to maximize the use of your vehicle when working hard or hardly working.



Full Time Half Tray Half Canopy Packages

Our full time half tray half canopy packages are a great alternative when you want the lockable dust & water free storage a canopy offers, but also need functional tray space for carrying those larger, sometimes dirty items. This package style provides you the best of both worlds when a full size tray isn’t needed and you don’t want the task of removing a jack off  style canopy. This setup brings with it the added benefits of keeping the complete package weight and cost down when compared to a standard tray with jack off style canopy as there is no headboard included due to the full time canopy taking it’s place. Our standard package configurations to select from include all standard tray sizes minus 70mm in overall length with either 920mm or 1120mm long full time half canopy.



 Converted 200 Series Landcruiser Ute Tray Packages

When you think king of the on and off-road you can’t go past the almighty 200 series landcruiser. Unfortunately these have only been made to the factory showroom floor as a wagon style vehicle. But what if you want the practicality of a load carrying tray or canopy on the back with the luxuries that only a 200 series offers up front. Well we work closely with and can recommend highly experienced, qualified and reputable conversion shops to take your 200 series and carry out the required conversion. Allowing NQ Ally Work to complete the package by adding an NQ Ally Works ute tray and or canopy package.



Converted & Extended 200 Series Landcruiser Ute Tray Packages

When you think 200 series, you think big! But some people just want and need to go bigger with a conversion including a chassis extension. Increasing the load carrying space of the vehicle, whilst moving the rear wheels back underneath the center of load to improve handling and ride performance. We recommend highly experienced, qualified and reputable conversion shops so your 200 series can have the required certified alterations carried out. We work closely with these experienced teams to allow us to then complete your big rig by adding an NQ Ally Works ute tray and or canopy package.



Complete Touring Packages

With a huge array of options to select from we have something to suit everyone’s needs allowing us to put together your perfect touring package. From modular options to fitment of additional accessories you deem necessary to get off grid and adventure in style and comfort. Whilst our core focus is the manufacture and fitment of aluminium ute tray, canopies and accessories we can source, supply and fit most additional requirements you may have saving you the leg work.



Standard Ute Tray Features

Signature Headboard

  • 1 piece mandrel bent and polished 63.5mm x 4mm tube main bar
  • 4mm cnc profile cut and pressed aluminium headboard panel
  • 2 x horizontal anchor tracks
  •  NQAW unique cnc profile cut mesh

Hardware

  • Stainless steel spring loaded sideboard over centre latches
  • Stainless steel sideboard hinge straps and gudgeon pins
  • Stainless steel anti drop R clips
  • Sideboard latch grips



Removable Sideboards

  • 288mm high
  • 4mm cnc profile cut and pressed end capping plates
  • Robust aluminium mig and tig welded construction
  • Intergrated internal tie-down rings

Flared Mudguards

  • 1 piece adjustable positioning
  • 2.5mm cnc profile cut and press aluminium construction
  • 4mm cnc profile cut and welded gusseting plates

Headboard Anchor Rings

  • Designed for use in headboard horizontal anchor tracks
  • 2 included with every tray
  • Adjustable & removable

Deck Plate



  • 4mm thick aluminium plate
  • Fully welded perimeter, stitch welded to sub-frame
  • 5083 hard marine grade

Sensor & Camera    Re-fitment

  • Re-fiment of rear cross traffic radar sensors
  • Re-fiment of rear parking sensors into lightboard
  • Re-fiment of reversing camera

      * Recalibration may be required

Lightboard Tie Down Points

  • 6mm cnc profile cut hard 5083 marine grade aluminium plate construction
  • Fully welded into tray main frame for strength
  • 1 positioned either side of under tray drawer lightboard passage.

LED Taillights

  • LED taillights wire by qualified automotive electrician to plug directly into vehicles factory wiring looms
  • 2 x std options available to select from
  • LED sequential indicator tail lights (Top)
  • LED maxi lamp taillights (Bottom)

OPTIONAL UTE TRAY ADD-ONS

Under Tray Toolboxes

  • Tig welded using 2.5mm flat aluminium sheet
  • Double fold gutter opening to eliminate water entry
  • Full perimeter toolbox sealing rubber to eliminate water and dust entry
  • Dual locking compression vector lock

Under Tray     Drawers

  • Available lengths 900mm & 1200mm
  • Dust & water proof bolt in unit with sealed outer casing and inner drawer body
  • 227kg heavy duty locking slides
  • Unique removable divider system (sold separately)

Under Tray Poly Tanks

  • Available in 45L or 75L
  • Food grade polyethylene construction, eliminating plastic taste
  • Includes headboard mounted filler neck and tank breather hose
  • Lockable brass tap mounted for convenient access

* Undertray tray drawers fitted in conjunction with an under tray poly tanks will only allow certain size configurations to fit. These are as follows based on a std 1800 long dual cab tray package. 900mm drawer with 45L/75L poly tank, 1200mm drawer with 45L poly tank.

Tradie Roof Rack

  • Available sizes 2330L x 1330W, 2600L x 1330W
  • Box section main frame construction supporting an aluminium mesh infill panel
  • Side frame trussed with 25mm tube top rail using unique dimpled side panels
  • Package must include a rear ladder rack, rear mounted dog cage or canopy to allow fitment of a tradie roof rack

Rear Ladder Racks

  • Constructed using cnc mandrel bent 63.5mm x 4mm aluminium tube
  • Top portion above sideboards exact profile and height to match headboard
  • Inwards offset mounting points to allow direct fixture to tray deck via a gusseted bolting plate using 4 x M10 SS bolts
  • Brushed finish to match headboard
  • Available in std sizes 1850W x 880H, 1850W x 1015H & 2000W x 880H

Paint Options

  • Carried out by local expert automotive spray painters
  • Various paint packages available
  • Basic paint package – sideboards (main body only) and toolbox doors
  • Full paint package – Complete package (excluding underside of tray & mudguards, internal of toolboxes, main tray deck
  • SS protective sideboard capping included with all painted sideboards

Dog Cages

  • Available in standard sizing only with tray package (not sold separately)
  • Sizing available, 1850W x 880H x 600L, 1850W x 1015H x 600L, 2000W x 880H x 600L
  • Available options, door dog head passages, swinging divider, fixed divider, floating floor, floating shelf

Recessed Anchor Rings

    • Heavy duty spring loaded anchor rings
    • Stainless steel construction
    • Recessed fitment below deck plate
    • Install location and orientation as per customer specification.

Rubber Ute Tray Matting



  • Breathable non slip rubber matting.
  • Great for stopping your load sliding around.
  • Cut to length
